Belt Conveyor is a kind of continuous transmission equipment which without immunity traction components, it uses rotation screw to convey material. The screw conveyor is of simple structure, low marking cost, strong sealing, safe ,convenient operation and other advantages, It allows multiple inlets and outlets. It is widely used in various industrial department(such as building materials, chemicals, electric power, metallurgy, coal, mine, food and other industries)to convey powder, granular and lump material, such as, coal, ash, slag, cement, food, etc. The temperature of material is less than 200°C. Screw conveyor is not suitable for transporting those material which is perishable, with big viscous and easy caking. In the concrete mixing plant screw conveyor's effect reflected to the fullest. Our company can design and manufacture special models based on your needs.
Main characteristics
1.Compact structure, small cross section, light weight
2.Good seal performance, good transportation efficiency
3.Flexible technological arrangement, easy to be installed , dismantle and moved, safe operation
4. Totally enclosed design for dust and vapor-tight requirements
5. Designs available for high temperature material
6. Ideal for abrasive, corrosive or other materials
Applicable materials
Loose materials such as powder, granular and small piece material , which includes: clay powder, pulverized coal, cement, sand, grain, small piece of coal , cobble, and cast iron filings, etc.
While it is not applicable for materials with high viscosity and easy to be curdled.
Widely applied:It is widely used for the loose cement transportation from cement warehouse to mixer or from cement warehouse to compounding machine in concrete mixing plant.
Technical Parameter:
LS Series
|
Model |
Diameter (mm) |
The distance of blades(mm) |
Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
|
D |
S |
n |
φ=0.33 |
n |
φ=0.33 |
n |
φ=0.33 |
n |
φ=0.33 |
|
|
LS100 |
100 |
100 |
140 |
2.2 |
112 |
1.7 |
90 |
1.4 |
71 |
1.1 |
|
LS125 |
125 |
125 |
125 |
3.8 |
100 |
3.0 |
80 |
2.4 |
63 |
1.9 |
|
LS160 |
160 |
160 |
112 |
7.1 |
90 |
5.7 |
71 |
4.5 |
56 |
3.6 |
|
LS200 |
200 |
200 |
100 |
12.4 |
80 |
9.9 |
63 |
7.8 |
50 |
6.2 |
|
LS250 |
250 |
250 |
90 |
21.8 |
71 |
17.2 |
56 |
13.6 |
45 |
10.9 |
|
LS315 |
315 |
315 |
80 |
38.8 |
63 |
30.5 |
50 |
24.2 |
40 |
13.4 |
|
LS400 |
400 |
355 |
71 |
62.5 |
56 |
49.3 |
45 |
38.6 |
36 |
31.7 |
|
LS500 |
500 |
400 |
63 |
97.7 |
50 |
77.6 |
40 |
62.0 |
32 |
49.6 |
|
LS630 |
630 |
450 |
50 |
138.5 |
40 |
110.8 |
32 |
88.6 |
25 |
69.3 |
|
LS800 |
800 |
500 |
40 |
198.5 |
32 |
158.8 |
25 |
124.1 |
20 |
99.3 |
LSY Series
|
Model |
Diameter (mm) |
The distance of blades(mm) |
Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
Speed (rpm) |
Capacity (t/m³) |
|
D |
S |
n |
φ=0.33 |
n |
φ=0.33 |
n |
φ=0.33 |
n |
φ=0.33 |
|
|
LSY100 |
100 |
100 |
140 |
2.2 |
112 |
1.7 |
90 |
1.4 |
71 |
1.1 |
|
LSY125 |
125 |
125 |
125 |
3.8 |
100 |
3.0 |
80 |
2.4 |
63 |
1.9 |
|
LSY160 |
160 |
160 |
112 |
7.1 |
90 |
5.7 |
71 |
4.5 |
56 |
3.6 |
|
LSY200 |
200 |
200 |
100 |
12.4 |
80 |
9.9 |
63 |
7.8 |
50 |
6.2 |
|
LSY250 |
250 |
250 |
90 |
21.8 |
71 |
17.2 |
56 |
13.6 |
45 |
10.9 |
|
LSY315 |
315 |
315 |
80 |
38.8 |
63 |
30.5 |
50 |
24.2 |
40 |
13.4 |
|
LSY400 |
400 |
355 |
71 |
62.5 |
56 |
49.3 |
45 |
38.6 |
36 |
31.7 |
|
LSY500 |
500 |
400 |
63 |
97.7 |
50 |
77.6 |
40 |
62.0 |
32 |
49.6 |
|
LSY630 |
630 |
450 |
50 |
138.5 |
40 |
110.8 |
32 |
88.6 |
25 |
69.3 |
|
LSY800 |
800 |
500 |
40 |
198.5 |
32 |
158.8 |
25 |
124.1 |
20 |
99.3 |
