Model | 3017GⅠ | 3017GⅡ | ||
Complete Equipment | Dimensions (mm) L x W x H | 8000 x 2800 x 3400 | 8000 x 2800 x 3400 | |
Total Weight (KG) | 16000 | 17800 | ||
Motor Power (KW) | 55 | 55 | ||
Diesel power(KW) | 92 | 92 | ||
Diesel | 6105 | 6105 | ||
Drive mode | Motor (diesel engine for power failure) | |||
Spray Arms | Maximum Spraying Height(M) | 17 | 17 | |
Maximum Work Depth(M) | 8 | 8 | ||
Slumping Range(mm) | 150-230 | 150-230 | ||
Boom Control Type | Wireless remote control and manual control, free option | |||
Effective distance of remote control(m) | 100 | 100 | ||
Pumping System | Concrete Spraying Capacity (m³/h) | 4-30 | 4-30 | |
System Pressure (MPa) | 20 | 20 | ||
Max. Theoretical Pumping Pressure (MPa) | 10 | 10 | ||
Distribution Valve | S-tube | S-tube | ||
Convey Cylinder Diameter ( mm) | 80 | 80 | ||
High pressure cleaning pumps | BYB-1-11 | BYB-1-11 | ||
Carrier | Steering Type | Four wheel hydraulic steering | Four wheel hydraulic steering | |
Driving directions | Two-way driving | Two-way driving | ||
Auxiliary System | Cable Length (m) | 100 | 100 | |
Convey capacity of accelerator pump(L/h) | 30~700 | 30~700 | ||
Convey pressure of accelerator(MPa) | Max:1.2 | Max:1.2 | ||
Metering pumps | ALH25 | ALH25 | ||
Air compressor power(kw) | / | 75 | ||
Air compressor capacity(m³/m) | / | 13 | ||
Working pressure of air compressor(MPa) | / | 0.8 | ||
