Home /Products/AAC Block Production Machine/Block Manufacturer AAC Production Line Concrete

Block Manufacturer AAC Production Line Concrete

1.0 Sets
MOQ
Block Manufacturer AAC Production Line Concrete
Features Gallery Product Description Request A Quote
Features
Specifications
Applicable Industries: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction Works
Showroom Location: Philippines, Indonesia, Pakistan, Thailand, Sri Lanka, Bangladesh, Uzbekistan
Condition: New
Type: Hollow Block Making Machine
Brick Raw Material: Sand
Processing: Brick Production Line
Method: Autoclaved Aerated Concrete
Automatic: Yes
Production Capacity (Pieces/8 Hours): 50000-300000m3/year
Voltage: 220V/380V/440V
Dimension(L*W*H): According To The Configuration
Warranty: 1 Year
Key Selling Points: Easy To Operate
Brick Size: 400*200*200 Mm
Machinery Test Report: Provided
Video Outgoing-inspection: Provided
Marketing Type: New Product 2020
Warranty Of Core Components: 1 Year
Core Components: Engine, Motor
After-sales Service Provided: Engineers Available To Service Machinery Overseas, Online Support, Free Spare Parts, Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support
Overseas Office: Indonesia/India/Vietnam/Brazil
Raw Material: Sand
Material: Fly Ash
Color: Opitional
Other Name: AAC BLOCK
After Warranty Service: Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service
Local Service Location: Philippines, Indonesia, Pakistan, India, Thailand, Kenya, Bangladesh, Kazakhstan
Certification: ISO9001/CE/TUV
Basic Infomation
Certification: ISO9001/CE/TUV
Payment & Shipping Terms
Packaging Details: standard seaworthy packing or nude packing
Supply Ability: 600 Set/Sets per Year
Product Description
Product Description
Aac Block Manufacturer Aac Plant Autoclaved Aerated Concrete Block Making Machinery
Areated concrete brick (light brick ) is the light and porous buidling material. It has light weight keeping temperature can't burn and other advantages.it can be made into many kinds of bricks(for example:600×200×100,80×80×180,240×115×53,600×200×125),they could be used industry building and common building.they are more and more popular in the world.in the future,they will replace the Clay brick completely.
Areated concrete common conception
Common concrete density is usually 1600-2400kg/m3,but Areated concrete are 500kg/m3,600kg/m3,700kg/m3.It has not the big grain,main use silicon material (for example:coal ash,sand,stone dust and others ),through making the material small for example
sand,they can be used directly if has enough degree of small (for example coal ash.Mixing calcium material lime cement water to a special slop,then add the aluminum dust and the additive.Make the aluminum dust and the special slop have a Chemical reflect.then
produce Hydrogen to make the concrete slop to expanding or swell,foam.Next,put them into the curing room to concreting cutting steaming curing,last,there will bacome the light brick,the porous rate is 70-80%.
Advantages
1)light weight
Areated concrete density is usually 400-700kg/m3,(according the market in produce ),same as 1/3 of clay brick and 1/5 common concrete.So use the Light brick can reduce the weight of the build more,and also reduce the beam of roof and pillar press best.then you can see,it can save the material and cost,it also fighting shaking.
2)keeping temperature
It has many porous,the delivery hearting coefficient is 0.9-0.22W/(mk),the same as 1/4 or 1/5 of clay brick,so it is best materials now in the world. Also many kinds raw material,have lowest wasteMain Material:coal ash sand waste mine material coal stone,stone dust and other silicon materials.
Detailed Images
Detailed Product Description
1)Foam block machine,best offer with most competitive price ,quality guarantee machine, any size block widely used for high buildings,walls, etc many many infrastructure projects.
2)We are the top leader in China on manufacturing the Autoclaved Aerated Concrete Line(AAC) with 65% market share. We have exported our lines to different countries -- Russia, Thailand, Ukraine, Middle East and so on.
3)We can supply our customer for designning, production, installation, commissioning, training and good after-sale service.
4)Capacity: from 50000 cubic meter to 300,000 cubic meters per year.
5)Equipments: stocking raw materials, mixing, molding, forming, cutting, evaporating and curing, crane cramp, transporting etc.

AAC Production Line/Autoclaved Aerated Concrete Production Line
1)Product weight is according to 600kg/m3 to control.
2)annual capacity 300,000M3.
3)set raw material proportion: cement 6.5%, raw lime 23%, flyash 68%, gypsum 3%, aluminum paste powder 350g/M3.
4)water and material rate 0.631
5)one mould product 2.88M3
6)Casting slurry cycle time 5-6 minutes, cut cycle time 5 minutes.
7)casting slurry temperature 38-42 degree
8)body quiet stop. Time is 1.5-2.5hours, temperature 50-90 degree, after quiet stop body strength is 0.15-0.18Mpa
9)Steam curing cycle time, come in and out autoclave about 0.5hour, steam curing cycle time about is 6 hours/1.6Mpa, total 6.5 hours.
10) Cement lime fly ash style aerated block raw material proportion
name
unit
proportion


flash
%
65-70


cement
%
6-15


lime
%
18-25


gypsum
%
3-5


Aluminum powder paste(600kg/m3)
1/10000
8


Water & material rate

0.60-0.65


Casting system
OC
36-40


Aluminum mixing time
S
30-40


Cement lime Sand style aerated block raw material proportion




Name
Unit
proportion


Sand
%
55-65


Cement
%
10-20


Lime
%
20-30


Gypsum
%
2-3


Aluminum powder paste(600kg/m3)
1/10000
8


Water & material rate

0.65-0.75


Casting system
OC
35-38


Aluminum mixing time
S
30-40


Reference: cement is 42.5 Portland or 42.5 common cement
Aluminum power paste calculate to use according to 600kg/m3
Remark: the accurate batching rate is adjustable according to the raw material locally
Related Products

Company Introduction
Certifications
Our Services
Pre-sale Service 1.We have full stock, and can deliver within short time.Many styles for your choices. 2.Good Quality + Factory Price + Quick Response + Reliable Service, is what we are trying best to offer you. 3.All of our products are produce by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service. After-sale Service 1.We are very glad that customer give us some suggestion for price and products. 2.If any question, please contact with us freely by E-mail or Telephone.
Packing&Shipping
FAQ
1.Q:What is the material of the brick?      A: Cement,sand,stone.fly ash,building waste and so on. 2.Q:What kind of the brick that the brick making machine can produce?      A: All kinds of the hollow block and paving brick. You can customize the type of brick. 3.Q:what is the driving power of the hollow block making machine?      A: Electricity and diesel engine. 4. Q: Are you a manufacturer of a trading company?   A:We are the biggest building materials machinery manufacturers, with strong technical force, reliable product quality, which merge science,industry and trade together in one.Welcome to our factory at any time. 5. Q: How can I pick up a suitable machine ?       A: Only clarify your required output per day or per shift (8 hours) as well as your budget, then we can recommend suitable machine with very competitive price. 6. Q: How about the installation ?    A: We support Overseas Installation for all our medium / big machines, small machines you will gain online video technical support (Trading company may not support). 7.Q: What kind of blocks can be produced by this plant?     A: You can get blocks with different sizes by changing the position of cutting wires. 8. Q: Can you assure the quality?     A: Yes, we can. Our equipment will be carefully tested before shipping, and can be used over 10 years. If you worry about that, we can make the translation via Trade Assurance Order on Alibaba. 9. Q: How can I get this plant?     A: You can visit our factory at first, and if you want to buy, we can transport the equipment to you by sea after we get the payments.
